3D Design

When working in the technical field it is also very important to be able to master the construction of non-existent objects to present the novelty to the web public as fast as possible.

The image of a product-to-be is necessary too, crucial sometimes, hence the construction/re-construction, reverse technology of objects and successive rendering.

If a photograph is worth a 1000 words, a 3D rendering may be worth a 1000 photographs, since certain details may be enhanced, details may be presented in a different way, some information may be hidden if necessary, and objects can be visualized from all sides.

3D rendering associated with line drawing Working area of Automatic Lathe with B axis accessory Group of mechanical parts in steel and brass Animated steel rendering of a lathe tool holder
Realistic rendering of mechanical part Realistic rendering of drilling section of automatic lathe machine Non-realistic rendering of turret lathe working area Non-realistic rendering of multi-spindle working area to better show surfaces and lines
Non-realistic rendering of automatic swiss type lathe working area Realistic rendering of drilling section of automatic lathe machine Realistic rendering of mechanical part Graphic representation of how certain lathe operation may be performed
photo gallery:

Integration of 3D with actual bitmaps for a brochure cover
